White Incandescent Lamp NSN:6240-00-019-3093 P/N:193093
Please fill out the form below for a price quote and availability on this item.
White Incandescent Lam- An item whose principal purpose is to produce light from a glowing filament(s). it includes metal backed and reflecting types, seal beam and flood types. it may include an integral filament shield to control and/or modify its illumination pattern.
| Emitted Light Characteristic: | White |
| Average Life Rating In Hours: | 1000.0 |
| Base Style: | Single contact bayonet candelabra |
| Bulb Designator: | G-6 |
| Bulb Light Transmission Characteristic: | Transparent |
| Bulb Style: | G (globular) |
| Burning Position: | Any acceptable |
| Current Rating For Which Designed: | 0.370 amperes nominal |
| For Use With/On: | Truck, fire/crash p2; vehicle, aircraft refueler r-14; m1a2 abrams tank, 2350-01-328-5964 (eaa cmbt85pk3); shipboard material handling equipment (mhe); cargo trailer, m105a3; m1a2 heavy assault bridge (hab) wolverine, 5420-01-430-4247; m1a2 system enhancement program, 2350-01-328-5964 (eaa cmbt85sep); aircraft, (ac-130h, mc-130h, ec-130e, hc-130); armored security vehicle, |
| Filament Designation: | 2c-2v |
| Filament Heavy Duty Service Rating: | Not rated |
| Overall Length: | 1.438 inches nominal |
| Light Center Length: | 0.750 inches nominal |
| Light Output Rating: | 6.000 spherical candlepower nominal single rating |
| Rated Average Life: | Hours |
| Voltage Rating: | 28.000 volts nominal |
| Wattage Rating: | 10.360 watts |
