U.S. Army Tank Automotive Command Spacing Threaded Standoff 1.438" X .625" NSN:5340-01-317-4800 Model:12337637-11

Regular price $12.99

Spacing Threaded Standoff

NSN: 5340-01-317-4800 | Model: 12337637-11
ITAR Registered seal

A standoff that must have a threaded en (s) or be internally threaded its full length. For items having external threads on both ends, see stud (as modified). For items with an outside contour that is the same for the entire length, are flat on top and bottom, having internal threads its full length, and the length does not exceed twice the width across the flats or outside diameter, see nut (as modified); use dimensions(s) for compliance.

NSN Properties and Flags
NATO Stock Number
Yes - ITAR Controlled
Thread Length
0.900 inches left internal (includes through thread)
0.625 inches
1.438 inches
Cross-sectional Shape
Special Features
Aluminum flux ball one end
Steel comp 1015 or steel comp 1016 or steel comp 1018 or steel comp 1020
Material Specification
Astm a108, grade 1015 assn standard 1st material response or astm a108, grade 1016 assn standard 2nd material response or astm a108, grade 1018 assn standard 3rd material response or astm a108, grade 1020 assn standard 4th material response
Style Designator
Left internal thread
