Magnetika TW-71381 Power Transformer NSN: 5950-01-174-7691

Please fill out the form below for a price quote and availability on this item.

Power Transformer

NSN:5950-01-174-7691     P/N:TW-71381    Model:13084025
ITAR Registered seal

A transformer consisting of one or more primary windin (s) and one or more secondary winding(s). It may be designed for direct connection to an alternating current source for purposes of changing the secondary volts and amperes or designed to eliminate metallic interconnection between circuits in an one to one voltage ratio, with or without additional output windings, or items designed to automatically maintain a constant output voltage within specified limits under varying input or load conditions. Also includes items having a provision for mechanically changing the turns ratio or inductive coupling in progressive increments by means of voltage taps, ratio adjuster, or devices oe similar design. For transformers having winding(s) common to both input and output circuits, see transformer (1), power, autotransformer. Excludes transformer (1) , pulse.

NSN Properties and Flags
NATO Stock Number
5950-01-174-7691
DEMIL
Yes - ITAR Controlled
Reliability Indicator
Not established
Center To Center Distance Between Mounting Facilities Parallel To Length
3.125 inches single mounting facility single center group
Center To Center Distance Between Mounting Facilities Parallel To Width
2.250 inches single mounting facility single center group
Overall Height
2.409 inches
Frequency Rating
400.0 hertz single component
Input-output Phase Relationship
Three phase to three phase single component
Transformer Winding Connection Type
Delta-delta
Maximum Transformer Power Rating
221.4 volt-ampere single component
Winding Shielding Method
Internal shield brought out to terminal single component
Body Length
3.780 inches
Body Width
2.900 inches
Maximum Operating Temp
155.0 degrees celsius
Inclosure Type
Fully enclosed
Mounting Facility Quantity
4 single group
Mounting Method
Threaded hole single group
Winding Function And Quantity
1 primary single component and 5 secondary single component
Thread Size
0.190 inches single group
Winding Operating Current
650.0 milliamperes dc single component 3rd secondary
Winding Power Rating
36.2 volts-amperes single component 4th secondary
Winding Operating Voltage
17.00 ac volts single component 1st secondary
Special Features
One primary and five secondaries
Thread Series Designator
Unf single group
Terminal Type And Quantity
19 turret



This product is only available upon request. Contact us by e-mail or by filling out the form below for a quote.
