Radio Frequency Transformer

NSN: 5950-00-837-6722  P/N:391-3814  Model: 24A226742-21-11
ITAR Registered seal

An item having either a single tapped winding (autotransformer type), or two or more win dings designed to furnish inductive reluctance and/or transfer electrical energy in circuits by means of a magnetic field. It is so designed that its entire intended range of operations is above 20 kilohertz (kilocycles). The value may extend into the audio frequency range (below 20 kilohertz). It may include integral capacitors, coils, resistors, and adjustable tuning cores. For items having only two active terminals see coil, radio frequency. Includes types having win dings which may be moved with respect to each other. Excludes transformer, discriminator.

NSN Properties and Flags
NATO Stock Number
5950-00-837-6722
DEMIL
Yes - ITAR Controlled
Reliability Indicator
Not established
Turn Quantity
16 single component single secondary
Inductance Rating
1.720 microhenries single component single secondary
Frequency Rating
12.0 megahertz single component and 14.0 megahertz single component
Coil Form Type
Hollow single component
Adjustment Device Drive Type
Slotted screw single component
Body Length
3.000 inches
Body Outside Diameter
0.201 inches
Inclosure Type
Open
Mounting Method
Clip single group
Rating Method
Electrical single component single primary and winding turns single component single primary
Winding Function And Quantity
1 primary single component and 1 secondary single component
Winding Conductor Size
0.01003 inches American wire gage single component single primary
Adjustment Method And Quantity
1 adjustable core single component
Terminal Type And Quantity
4 wire lead
