SKF Chicago Rawhide 49985 Joint Radial Oil Seal NSN: 5336-00-978-0900

Please fill out the form below for a price quote and availability on this item.

Plain Encased Seal

NSN: 5330-00-978-0900 | Model: 00044
ITAR Registered seal

A pliable rubber, felt, leather, or composition ring-shaped element, split or solid; with or without spring or spreader, having a metal shell on all or a portion of at least two of the outer surfaces. It may be designed to be either bolt mounted or pressmounted between fixed and moveable parts to form a tight and effective seal by the pressure of the spring or spreader or the resiliency inherent in the element material. Excludes packing with retainer.

NSN Properties and Flags
NATO Stock Number
5330-00-978-0900
DEMIL
Yes - ITAR Controlled
Outside Diameter
6.256 inches
Tempurature Rating
-65.0 degrees Fahrenheit and 225.0 degrees Fahrenheit
Accommodated Shaft Diameter
5.000 inches
Seal Width
0.500 inches
Accommodated Shaft Maximum Rated Speed
3600 feet per minute
Case Style
Recessed
Housing Bore Diameter
6.250 inches
Sealing Element Style
Angular-opposed
Material
Steel case
Surface Treatment
Plastic case



This product is only available upon request. Contact us by e-mail or by filling out the form below for a quote.
