Pall
New!!! Pall HC-7500SUK-4H Hydraulic Filter Element NSN:4330-01-183-4514
Regular price
$34.99
Fluid Filter Element
NSN: 4330-01-183-4514 | Model: HC-7500SUK-4HA replaceable device designed to remove solid particles from fluids ranging in density from heavy liquids to gases. The removal of particles is accomplished by porous material (metallic or non-metallic), stacked disks, wound wire, or the like, constructed so the fluid can flow through the device while the solid particles are retained. It may be designed to fit into a filter, fluid (or similar cavity), or it may have an integral outer casing and mounting facilities and be designed to connect directly to an engine, compressor, or the like. The degree of removal of particles must be ly rated at less than 50 microns or absolutely rated at less than 75 microns. Excludes filter element, air conditioning. See also strainer element, sediment.
NSN Properties and Flags
NATO Stock Number
4330-01-183-4514
DEMIL
Yes - ITAR Controlled
Filtration Rating In Microns
3.0 absolute
Flow Direction
Outside in
Design Type
Nonreusable
Tempurature Rating
Between -65.0 degrees Fahrenheit and 225.0 degrees Fahrenheit
Bodylength
4.000 inches
Filtering Media Design
Pleated single filtering media response
Filtering System For Which Designed
Full flow
Special Features
Spin-on type
Material
Rubber buna n seal
Media For Which Designed
Any acceptable
Style Designator
Cylindrical w/ integral outer casing
