Military Specifications M39016/13-063P Electromagnetic Relay 26.5VDC 2A NSN:5945-01-245-2265

Regular price $34.99

Electromagnetic Relay

NSN: 5945-01-245-2265 | Model: M39016/13-063P
ITAR Registered seal
  • 5945-01-245-2265 replaces 5945-01-029-5583
Schedule B & Trade:
  • Schedule B: 8536490050 (NAICS 335314)

    Relays, electromechanical, with contacts rated at less than 10 a, for a voltage exceeding 60 v but not exceeding 1000 v

  • SITC: 77254

    Relays for electrical apparatus used with electrical circuits not exceeding 1, 000 volts

  • End Use: 20005

    Electric apparatus

NSN Properties and Flags
NATO Stock Number
Yes - ITAR Controlled
Overall Length
1.062 inches
Center To Center Distance Between Mounting Facilities Parallel To Length
0.850 inches single mounting facility
Overall Height
0.320 inches
Overall Width
0.320 inches
Case Material
Environmental Protection
Unthreaded Mounting Hole Diameter
0.096 inches single mounting facility
Fragility Factor
Moderately rugged
Winding Quantity
Purpose For Which Designed
Coil Quantity
Winding Dc Resistance Rating
1.35 kilohms single winding
Duty Type
Arc Quenching Method
Mounting Facility Type And Quantity
2 unthreaded hole single mounting facility
Storage Type
General purpose warehouse
Cubic Measure
0.109 cubic inches
Mounting Facility Pattern
In-line single mounting facility
Nonpile-up Main Contact Arrangement
2 pole, double throw, one position momentary
Criticality Code Justification
Time Delay
0.004 seconds fixed operate and release time
Operating Voltage Rating And Type At Specificationified Temp
26.5 volts dc 25 degrees celsius single winding
Main Contact Load Current Rating At Maximum Rated Voltage
125.0 milliamperes ac resistive load and 2.0 amperes dc resistive load
Main Contact Maximum Voltage Rating In Volts
115.0 ac and 28.0 dc
Special Features
Failure rate level 0.1 percent
Test Data Document
81349-mil-r-39016 specification (includes engineering type bulletins, brochures, etc., that reflect specification type data in specification format; excludes commercial catalogs, industry directories, and similar trade publications, reflecting general type data on certain environmental and performance requirements and test conditions that are shown as "typical", "average", "", etc.).
Terminal Type And Quantity
8 wire lead all functions
Specification Data
81349-mil-r-39016/13 government specification
