Magnecraft W67CPSOX-4 Electromagnetic Relay 5A 28VDC NSN:5945-01-159-4123
Regular price
$65.99
Electromagnetic Relay
NSN:5945-01-159-4123 P/N:W67CPSOX-4 Model:RE0077A relay which is actuated by the effect of a magnetic field developed by the current in its energizing coi (s) . Includes solenoid and armature types. Excludes contactor, magnetic; relay, meter movement; relay, motor driven; relay, reed; relay, resonant reed; relay, rotary; and switch, stepping.
NSN Properties and Flags
NATO Stock Number
5945-01-159-4123
DEMIL
Yes - ITAR Controlled
Thread Class
2a single mounting facility
Thread Direction
Right-hand single mounting facility
Overall Length
1.374 inches
Overall Height
1.358 inches
Overall Width
0.734 inches
Environmental Protection
Dustproof
Fragility Factor
Moderately rugged
Contact Material
Silver
Contact Surface Treatment
Gold flash
Winding Quantity
1
Purpose For Which Designed
General
Coil Quantity
1
Duty Type
Continuous
Mounting Facility Type And Quantity
1 threaded stud single mounting facility
Storage Type
General purpose warehouse
Features Provided
Polarized
Thready Qty Per Inch (tpi)
48 single mounting facility
Thread Size
0.099 inches single mounting facility
Nonpile-up Main Contact Arrangement
2 pole, double throw, one position momentary
Operating Current Rating And Type
40.0 milliamperes dc single winding
Time Delay
1.00 seconds adjustable operate time and 240.00 seconds adjustable operate time
Operating Voltage Rating And Type At Specificationified Temp
24.0 volts dc 25 degrees celsius single winding
Main Contact Load Current Rating At Maximum Rated Voltage
5.0 amperes ac resistive load and 5.0 amperes dc resistive load
Main Contact Maximum Voltage Rating In Volts
120.0 ac and 32.0 dc
Precious Material And Location
Contacts silver and contact surfaces gold
Precious Material
Silver and gold
Thread Series Designator
Unc single mounting facility
Terminal Type And Quantity
8 tab, solder lug all functions
