Light Lens NSN:6220-01-476-6216 P/N:631-321-015
Please fill out the form below for a price quote and availability on this item.
Light Lens- A transparent or translucent item designed to enclose or be placed in front of a light source. sections of the lens may be opaque. it may or may not include a holder. it is designed to be either a replacement unit for a specific type of light, such as light, indicator; light, navigational, marine; stop light, vehicular; and lantern, electric or that portion of a switch, (as modified) used as an actuator and having provisions for illumination. see also, window, lighting fixture; globe; electric light; and filter (2), (as modified).
| Effective Length: | 0.520 inches nominal |
| Effective Width: | 0.520 inches nominal |
| For Use With/On: | Aircraft, stratolifter c-135 |
| Color: | Clear lens |
| Flange Width: | 0.225 inches nominal |
| Material: | Aluminum alloy base |
| Mounting Method: | Flange |
| Mounting Slot Depth: | 0.225 inches nominal |
| Mounting Slot Width: | 0.030 inches minimum and 0.250 inches maximum |
| Overall Height: | 0.248 inches nominal |
| Overall Length: | 0.745 inches nominal |
| Light Transmission Design: | Translucent lens |
| Overall Width: | 0.745 inches nominal |
| Part Name Assigned By Controlling Agency: | Pushbutton |
| Special Features: | Lens is a horizontally split, pushbutton display with visible legends; top legend mfd ctl, bottom legend ctr mfd control: also has a green in color filter |
| Specific Use: | Panel light |
| Style Designator: | Convex |
| Supplementary Features: | Operating characteristics: activation force is five pounds maximum. activation travel is 0.125 inches with a 0.025 inch tolerance. pushbutton extraction force is two to five pounds |
| Surface Condition: | Smooth face |
| Surface Condition: | Smooth back |
This product is only available upon request. Contact us by e-mail or by filling out the form below for a quote.
