Light Indicator NSN:6210-01-263-5317 P/N:10620DC9-1035
Please fill out the form below for a price quote and availability on this item.
Light Indicator- A light, with mounting facilities furnished, designed to convey information of a specific nature concerning the circuit in which inserted. must include or provide for the use of a lens as a part of it. for items without a lens, see lampholder, and also see light (1), panel.
| Furnished Items And Quantity: | 1 mounting sleeve |
| Filter Color: | Amber single light 1st position horizontal horizontal split display division a |
| Filter Color: | Red single light 1st position horizontal horizontal split display division b |
| Filter Quantity: | 2 |
| Material: | Steel corrosion resisting body |
| Mounting Method: | Sleeve |
| Overall Height: | 0.750 inches nominal |
| Lamp Base Type Accommodated: | Midget flanged |
| Lamp Bulb Size Designator: | T-1 3/4 |
| Lamp Type Accommodated And Quantity: | 4 incandescent |
| Lens Back Surface Condition: | Painted single light 1st position horizontal |
| Lens Color: | Gray single light 1st position horizontal |
| Lens Face Surface Condition: | Smooth single light 1st position horizontal |
| Lens Legend: | No go single light 1st position horizontal horizontal split display division b |
| Lens Legend: | Ready single light 1st position horizontal horizontal split display division a |
| Lens Light Transmission Characteristic: | Translucent single light 1st position horizontal |
| Lens Quantity: | 1 |
| Lens Type: | Flat, rectangular single light 1st position horizontal |
| Overall Length: | 1.970 inches maximum |
| Overall Width: | 0.750 inches nominal |
| Style Designator: | Rectangular frame type |
| Terminal Type And Quantity: | 3 solder lug |
| Transmitted Legend Color: | Amber single light 1st position horizontal horizontal split display division a |
| Transmitted Legend Color: | Black single light 1st position horizontal horizontal split display division b |
| Transmitted Light Color: | Black single light 1st position horizontal horizontal split display division a |
| Transmitted Light Color: | Gray single light 1st position horizontal horizontal split display division b |
This product is only available upon request. Contact us by e-mail or by filling out the form below for a quote.
