Indicator Light NSN:6210-01-198-5622 P/N:6981ED166-689
Please fill out the form below for a price quote and availability on this item.
Indicator Light- A light, with mounting facilities furnished, designed to convey information of a specific nature concerning the circuit in which inserted. must include or provide for the use of a lens as a part of it. for items without a lens, see lampholder, and also see light (1), panel.
| Furnished Items And Quantity: | 10 flat washer and 1 gasket and 8 screw |
| Features Provided: | Transformer |
| Hazardous Locations/environmental Protection: | Shock proof and watertight |
| Material: | Copper alloy body |
| Mounting Method: | Unthreaded hole |
| Multilamp Circuit Type: | Two lamp common |
| Overall Height: | 1.750 inches nominal |
| Lamp Base Type Accommodated: | Midget screw |
| Lamp Bulb Size Designator: | T-1 3/4 |
| Lamp Industry Number: | 1769 |
| Lamp Type Accommodated And Quantity: | 2 incandescent |
| Lens Back Surface Condition: | Smooth single light 1st position horizontal |
| Lens Color: | White single light 1st position horizontal |
| Lens Face Surface Condition: | Smooth single light 1st position horizontal |
| Lens Legend: | Motor off;power;available single light 1st position horizontal full display division a |
| Lens Light Transmission Characteristic: | Translucent single light 1st position horizontal |
| Lens Mounting Method: | Push in |
| Lens Quantity: | 1 |
| Lens Type: | Flat, rectangular single light 1st position horizontal |
| Special Features: | 117v 60 cycles |
| Overall Length: | 2.638 inches nominal |
| Overall Width: | 2.125 inches nominal |
| Style Designator: | Rectangular frame type |
| Terminal Type And Quantity: | 2 screw |
| Transmitted Light Color: | White single light 1st position horizontal full display division a |
| Transmitted Legend Color: | Black single light 1st position horizontal full display division a |
This product is only available upon request. Contact us by e-mail or by filling out the form below for a quote.
