Incandescent Lamp NSN:6240-00-155-7804 P/N:PR8
Please fill out the form below for a price quote and availability on this item.
Incandescent Lamp- An item whose principal purpose is to produce light from a glowing filament(s). it includes metal backed and reflecting types, seal beam and flood types. it may include an integral filament shield to control and/or modify its illumination pattern.
| Emitted Light Characteristic: | Colorless |
| Average Life Rating In Hours: | 10.0 |
| Base Style: | Single contact miniature flanged |
| Bulb Light Transmission Characteristic: | Transparent |
| Bulb Style: | B (arbitrary designation) |
| Burning Position: | Any acceptable |
| Bulb Designator: | B-3 1/2 |
| Current Rating For Which Designed: | 0.600 amperes nominal |
| Filament Designation: | C-2r |
| Filament Heavy Duty Service Rating: | Not rated |
| Overall Length: | 1.250 inches maximum |
| Light Center Length: | 0.250 inches nominal |
| Rated Average Life: | Hours |
| Specification/standard Data: | 08108-pr-8 manufacturers standard |
| Voltage Rating: | 1.900 volts nominal |
| Wattage Rating: | 1.140 watts |
This product is only available upon request. Contact us by e-mail or by filling out the form below for a quote.
