Hubbell HBL5461I, Single Receptacle, 20A /250V / 2 Pole /3 Wire Grounding, Ivory
Hubbell HBL5461I, Single Receptacle. 20A / 250V / 2 Pole / 3 Wire Grounding, Ivory
Part No. HBL5461I
New
Hubbell HBL5461I, Single Receptacle. 20A / 250V / 2 Pole / 3 Wire Grounding, Ivory
Straight Blade Receptacle, Current Rating 20 Amps, Voltage Rating 250 Volts, Power Rating 2 HP, NEMA Configuration 6-20R, Type Single, Color Ivory, Heavy Duty, Back/Side Wired
|
Voltage |
250 |
|
Voltage Rating |
250V |
|
Wattage |
5000 |
|
Weight |
0.20 |
|
Wire Size |
#14 AWG to #12 AWG |
|
Wiring |
Back, Side |
|
Special Features |
Self Grounding |
|
Standard |
NEMA WD1 and WD5, UL 498 |
|
Sub Brand |
Straight Blade Devices |
|
Type |
Single Receptacle |
|
Mounting |
Screw Mount |
|
NEMA Configuration |
6-20R |
|
NEMA Rating |
6-20R |
|
Nema |
6-20R |
|
Number of Poles |
2-Pole |
|
Number of Wires |
3-Wire Grounding |
|
Phase |
Single Phase |
|
Product Type |
Flush Receptacle |
|
Rating - Amps |
20 |
|
Rating - Volts |
250V AC |
|
Connection |
Back and Side Wired Screw Terminals |
|
Constructional Feature |
Impact Resistant |
|
Country of Origin |
USA |
|
Environmental Conditions |
Indoor Dry unless protected by additional means |
|
GTIN |
00783585013961 |
|
Grade |
Specification |
|
Ground |
Grounding |
|
Ground Type |
Grounding |
