33ft Suction Hose Assembly NSN:4720-01-293-5703 P/N:5-45-4906
Regular price
$129.00
Hose Assembly- A length of nonmetallic hose with fittings on one or both ends. for items without fittings, see hose, nonmetallic. excludes hose assembly, air duct; and hose assembly, air duct, air breathing.
P/N 813615-45-4906, Inside Diameter: 1.25in, Outside Diameter: 1.75in, Length: 396in
| Cross-sectional Shape Style: | Round |
| Exterior Color: | Black |
| Maximum Operating Pressure: | 200.0 pounds per square inch |
| Measuring Method And Length: | 396.000 inches nominal excluding end fittings |
| Media For Which Designed: | Water single response |
| Outside Diameter: | 1.750 inches nominal |
| Inside Diameter: | 1.250 inches nominal |
| Inside Surface Condition: | Smooth |
| Special Features: | C/o hose,nonmetallic,suction pn 5-45-4885; coupling half,quick disconnect,female,hose shank,1.25 pn ms27025-7; strainer assembly,suction hose pn 5-45-4905; 2-hose clip,1.75 od hose pn a3868; and nut,self-locking,hex,steel,0.25-20unc-3b pn ms51943-31 |
| Temp Rating: | 250.0 deg fahrenheit single response and -40.0 deg fahrenheit single response |
