Hewlett Packard

Hewlett Packard Power Supply NSN:6130-01-386-2854 Model:6038A-120-908

Regular price $2,499.99

Power Supply

NSN: 6130-01-386-2854 | Model: 6038A-120-908
ITAR Registered seal

A component which converts available alternating current or direct current electrical power into a form required to operate another component or set. The item may consist of a combination of an invertor, vibrator; vibrator, interrupter; vibrator, self-rectifying; invertor, power, static; with a transformer and rectifier (s) employing electron tubes, semiconductor diode or metallic (dry disc) type components, or the synchronized secondary contact(s) of a vibrator, self-rectifying; or may consist of electron tubes, semiconductor diode or metallic (dry disc) type rectifiers and capacitors in transformerless (alternating current-direct current type) circuits which may be of the voltage-multiplier type. The item may incorporate a filter, direct current power and provisions for regulation of input and/or output voltage. The item may have special input, output, control or other facilities for applications in specialized environments such as medical, dental or other operations. Excludes battery chargers and rotating machinery types of items, such as motor generators and dynamotors.

NSN Properties and Flags
NATO Stock Number
6130-01-386-2854
DEMIL
Yes - ITAR Controlled
Overall Length
17.872 inches
Overall Height
6.970 inches
Overall Width
8.360 inches
End Application
AN/GSM-348
Electrical Power Source Relationship
Operating
Input Phase
Single single operating power rqmt
Input Voltage Rating
104.0 ac pounds per hour dry single operating power rqmt and 127.0 ac pounds per hour with retaining chain single operating power rqmt
Output Voltage Rating
0.0 dc volts single power output and 60.0 dc volts single power output
Input Frequency Rating
48.0 hertz single operating power rqmt and 63.0 hertz single operating power rqmt
Features Provided
Over voltage protector and variable output rotary switch and programmable
Output Current Rating
10.0 dc amperes single power output
Output Control Location
Front panel single power output
Output Connection Quantity
1 single power output
Output Connection Type
Terminal strip single power output
Input Current Rating
6.5 ac amperes single operating power rqmt
Ventilation Design Type
Convection
Special Features
Option 908 rack mount kit for a single unit and a blank filler panel
