Greyhill M3786/4-0870 Explosion Proof Rotary Switch NSN:5930-00-428-6617

Regular price $28.99

Rotary Switch

NSN: 5930-00-428-6617 | Model: M3786/4-0870
ITAR Registered seal
  • 5930-00-428-6617 replaces 5930-00-996-1241
Schedule B & Trade:
  • Schedule B: 8536509025 (NAICS 335931)

    Switches, rotary, rated at over 5 a, for a voltage not exceeding 1, 000 volts

  • SITC: 77255

    Switches for electrical apparatus, n.E.S., for voltages not exceeding 1, 000 volts

  • End Use: 20005

    Electric apparatus

NSN Properties and Flags
NATO Stock Number
Yes - ITAR Controlled
Thread Class
2a single mounting facility
Thread Length
0.437 inches single mounting facility
Hazardous Locations/environmental Protection
Explosion proof
Overall Length
1.899 inches
First Flat Length
0.250 inches single actuator
Flat Height
0.216 inches single actuator
Shaft Diameter
0.250 inches single actuator
Shaft Length
0.437 inches single actuator
Overall Diameter
Between 1.000 inches and 1.306 inches
Nonturn Device Radius
0.375 inches at 3: 00 o'clock
Individual Section Quantity
Nonturn Device Type
Tab at 3: 00 o'clock
Operating Tempurature Range
-65.0/+85.0 degrees celsius
Switch Contact Basic Design
Nonpile-up symmetrical
Pole Quantity
1 single section front
Throw Quantity
7 single section rear
Mounting Method
Threaded bushing single mounting facility
Thread Size
0.375 inches single mounting facility
Contact Voltage Rating In Volts
28.0 dc at sea level
Shaft Flat/slot Angular Location
195.0 degrees from nonturn device single actuator
Rotor Through Connection Quantity
1 single section
Switch Actuator Indexing Position Quantity
7 single actuator
Shaft Type
Round, flatted single actuator
Terminal Type
Tab, solder lug
Contact Switching Action
Breaks before makes single section rear
Switch Actuator Positioning Increment
45.0 degrees single actuator
Detent Rotational Torque Range
+0.500/+2.500 inch-pounds single actuator
Switch Actuator Stop Device Type
Fixed stop single actuator
Contact Load Current Rating
75.0 milliamperes resistive load ac at sea level
Style Designator
Tap, circular, bushing mount
Test Data Document
81349-mil-s-3786 specification (includes engineering type bulletins, brochures, etc., that reflect specification type data in specification format; excludes commercial catalogs, industry directories, and similar trade publications, reflecting general type data on certain environmental and performance requirements and test conditions that are shown as "typical", "average", "", etc.).
Thread Series Designator
Unef single mounting facility
Specification Data
81349-mil-s-3786/4 government specification
