Magnecraft W78CSX-3 Relay 24 VDC, 120VAC, 3A NSN:5945-00-164-9883
Please fill out the form below for a price quote and availability on this item.
Electromagnetic Relay
NSN:5945-00-164-9883 P/N:W78CSX-3 Model:KHU17D1124VDC
Replacements:
- 5945-00-164-9883 replaces 5945-00-495-6191
- 5945-00-164-9883 replaces 5945-00-893-9445
- 5945-00-164-9883 replaces 5945-01-039-0393
- 5945-00-164-9883 replaces 5945-01-099-3592
Schedule B & Trade:
- Schedule B: 8536490050 (NAICS 335314)
Relays, electromechanical, with contacts rated at less than 10 a, for a voltage exceeding 60 v but not exceeding 1000 v
- SITC: 77254
Relays for electrical apparatus used with electrical circuits not exceeding 1, 000 volts
- End Use: 20005
Electric apparatus
NSN Properties and Flags
NATO Stock Number
5945-00-164-9883
DEMIL
NO
Overall Length
1.624 inches
Overall Height
0.859 inches
Overall Width
1.109 inches
Environmental Protection
Dustproof
Contact Material
Silver
Contact Surface Treatment
Gold flash
Winding Quantity
1
Coil Quantity
1
Winding Dc Resistance Rating
650.0 ohms single winding
Duty Type
Continuous
Mounting Facility Type And Quantity
1 threaded stud single mounting facility
Nonpile-up Main Contact Arrangement
4 pole, double throw, one position momentary
Time Delay
0.013 seconds fixed operate time
Operating Voltage Rating And Type At Specificationified Temp
24.0 volts dc 25 degrees celsius single winding
Main Contact Load Current Rating At Maximum Rated Voltage
3.0 amperes ac resistive load and 3.0 amperes dc resistive load
Main Contact Maximum Voltage Rating In Volts
120.0 ac and 28.0 dc
Precious Material And Location
Contacts silver and contact surfaces gold
Precious Material
Silver and gold
Terminal Type And Quantity
14 pin all functions
This product is only available upon request. Contact us by e-mail or by filling out the form below for a quote.
