Electrical Plug Connector NSN: 5935-01-006-7776 P/N: 1-229912-1
Please fill out the form below for a price quote and availability on this item.
Electrical Plug Connector
SKU: 5935010067776 | Model: 1-229912-1
NSN 5935-01-006-7776
Specifications from the Manufacturer
Thread Class:
2b
Thread Direction:
Right-hand
Overall Length:
3.837 inches nominal
Overall Width:
0.725 inches nominal
Cable Entrance Diameter:
0.475 inches nominal
Threaded Device Type:
Coupling facility
Mating End Quantity:
1
Contact Removability:
Removable single mating end single contact grouping
Polarization Method:
Mating end
Connector Locking Method:
Screw
Connector Cable Strain Relief Method:
Cable clamp
Nominal Thread Size:
0.112 inches
Terminal Location:
Back single mating end single contact grouping
Contact Material:
Copper alloy single mating end single contact grouping
Contact Surface Treatment:
Gold single mating end single contact grouping and nickel single mating end single contact grouping
Insert Material:
Plastic single mating end
Included Contact Quantity:
50 single mating end single contact grouping
Included Contact Type:
Leaf spring single mating end single contact grouping
Precious Material And Location:
Contact surfaces gold
Precious Material And Weight:
0.050 gold grains, troy
Precious Material:
Gold
Thread Series Designator:
Unc
This product is only available upon request. Contact us by e-mail or by filling out the form below for a quote.
