(2PC) C2G RJ45/DB9M Modular Adapter CTG #02946 NSN:5935-01-504-6149 P/N:adbj20-E3-pl75X

Please fill out the form below for a price quote and availability on this item.

Connector Adapter

NSN: 5935-01-504-6149 | Model: ADBJ20-E3-PL75X
ITAR Registered seal

An adapter with electrical contacts which provides facilities for joining two or more electrical connectors, whose design or function will not normally warrant their junction. it is not designed for permanent attachment to a cable, cord, coaxial line, or wire. the physical shape of an electrical connector should not be the determining factor of its name. tee, angle, straight, and y-shaped adapters are all adapter, connector. excludes adapter, connector to lamp base adapter, lamp holder to connector; adapter (1), cable clamp to connector; and adapter, lampholder. for items designed as a mechanical connection between an electrical conduit and an electrical connector, see adapter (1), electrical conduit.

NSN Properties and Flags
NATO Stock Number
Yes - ITAR Controlled
Body Style
Straight shape, external/internal coupling
Overall Length
1.656 inches
Overall Diameter
0.593 inches
Mating End Quantity
Contact Position Arrangement Style
Bnc all mating ends
Connector Locking Method
Bayonet pin and bayonet slot
Radio Frequency Type Contact Characteristic Impedance In Ohms
50.0 all mating ends single contact grouping
Shell Surface Treatment
Included Contact Quantity
1 all mating ends single contact grouping


This product is only available upon request. Contact us by e-mail or by filling out the form below for a quote.
