Brookfield
Brookfield Safety Wire, Nickel Alloy, 331 ft, P/N: MS20995NC32, NSN:9525-00-355-6072
Regular price
$12.99
Nonelectrical Wire
NSN: 9525-00-355-6072 | Model: MS20995-NC32A ferrous or nonferrous wire having a solid cross section that is square or rectangular with sharp or rounded corners or edges, or is round, half-round, hexagonal, or octagonal and whose diameter, width, or greatest distance between parallel faces is less than 3/8 inch or 10.0MM. The rectangular shape is limited to a thickness less than 3/32 inch or 2.5MM and a width of 1 1/4 inch or 30.0MM or less. For dimensions greater than above, see bar, metal. Excludes items having electrical resistivity or conductivity ratings.
NSN Properties and Flags
NATO Stock Number
9525-00-355-6072
DEMIL
Yes - ITAR Controlled
Length
331.000 feet
Cross Section Outside Diameter
0.032 inches
Basic Shape Style
Round
Weight Per Unit Measure
1.000 pounds per piece
Heat Treatment
Annealed
Material
Nickel, QQ-N-281, class a
Material
Nickel alloy 400
Material Specification
QQ-N-281, class a federal specification single material response
Nondefinitive Specification/std Data
Class a, form 7 and condition annealed
