Battery Charger Industrial Under Warranty Exide, G3-18-865 NSN: 6130-01-318-5822

Regular price $995.00

NSN: 6130-01-318-5822

A device consisting of one or more components utilizing an alternating or direct current source to reactivate batteries in which reversible chemical reactions occur. use only for devices containing resistors, metallic, or electronic type rectifiers or vibrators and which are specifically designed for the purpose of charging batteries. may include filters, meters, load contactor and alarm circuits. includes battery charging switchboards which are supplied with integral or external means of rectification.

Battery Type For Which Designed: Lead-acid
Charger Type: Solid state semiconductor
Charging Current Rating In Amps: 140.000 nominal
Charging Regulation Method: Controlled
Charging Voltage In Volts: 30.0 minimum and 45.0 maximum
Frequency Rating: 47.0 hertz minimum and 63.0 hertz maximum
Functional Description: Asolid state silicon controlled rectifier controlled unit that charges18 cell lead acid batteries
Overall Depth: 18.000 inches nominal
Overall Height: 30.000 inches nominal
Regulation Type: Multiple stages
Overall Width: 24.000 inches nominal
Phase: Three
