Amphenol Connector P/N:57-30500-3 NSN:5935-00-261-6524

Regular price $8.99

Reference Drawing:

[drawing of 5935-00-261-6524]

Electrical Plug Connector

SKU: 5935002616524 | Model: 57-30500-3
NSN 5935-00-261-6524NSN 5935-00-261-6524

Specifications from the Manufacturer

Body Style:
Hood, top opening w/clamp
Overall Length:
2.947 inches nominal
Overall Height:
2.125 inches nominal
Overall Width:
1.825 inches nominal
Cable Entrance Diameter:
0.473 inches nominal
Mating End Quantity:
1
Contact Position Arrangement Style:
2 rows of independent contacts inserted board single mating end
Contact Removability:
Nonremovable single mating end single contact grouping
Contact Maximum Current Rating In Amps:
5.0 single mating end single contact grouping
Polarization Method:
Mating end
Shell Type:
Hood, top opening
Connector Locking Method:
Latch
Connector Cable Strain Relief Method:
Cable clamp
Terminal Location:
Back single mating end single contact grouping
Contact Material:
Cadmium single mating end single contact grouping and copper single mating end single contact grouping
Contact Surface Treatment:
Gold single mating end single contact grouping and copper single mating end single contact grouping
Insert Material:
Plastic diallyl phthalate single mating end
Terminal Type:
Tab, solder lug single mating end single contact grouping
Shell Material:
Copper alloy
Shell Surface Treatment:
Zinc and chromate
Insert Material Document And Classification:
Mil-m-14,type mdg mil spec single material response single mating end
Included Contact Quantity:
50 single mating end single contact grouping
Included Contact Type:
Leaf spring single mating end single contact grouping
Precious Material And Location:
Contact surfaces gold
Precious Material And Weight:
0.050 gold grains, troy
Precious Material:
Gold
