Ammeter P/N: 8896644 NSN: 6625-00-643-3502

Please fill out the form below for a price quote and availability on this item.

Ammeter- An instrument which measures electric current and is calibrated and marked in amperes or any multiple and/or submultiple thereof. the value may be expressed by means of a pointer and calibrated dial or a digital readout display. for current detecting type of devices, see galvanometer.

Accuracy In Percent: -2.0/+2.0 at full scale single indicator single range
Background Color: White single indicator single range
Circuit Attachment Method And Quantity: 2 solder stud
Circuit Current For Which Designed: Dc
Dial Scale Marking Color: Black single indicator single range
Dielectric Withstanding Voltage In Volts: 3000.0
Features Provided: Magnetic shield
Measurement Range: +0.0/+500.0 milliamperes, dc single indicator single range
Meter Body Diameter Behind Mounting Flange: 2.800 inches nominal
Meter Depth Behind Mounting Flange: 1.660 inches nominal
Mounting Arrangement Style: Three hole/stud bolt circle
Mounting Bolt Circle Diameter: 3.160 inches nominal
Mounting Facility Type And Quantity: 1 flange
Movement Suspension Method: Metal pivot base
Movement Type: Moving coil, permanent magnet
Overall Diameter: 3.510 inches nominal
Installation Design: Panel
Scale Division Quantity: 6 single indicator single range
Sensitivity Rating: 150.0 millivolts
Overall Length: 2.060 inches nominal
Style Designator: Round flush mtg
Test Data Document: 81349-mil-10304a specification (includes engineering type bulletins, brochures,etc., that reflect specification type data in specification format; excludes commercial catalogs, industry directories, and similar trade publications, reflecting general type data on certain environmental and performance requirements and test conditions that are shown as "typical", "average", "nominal", etc.).

    This product is only available upon request. Contact us by e-mail or by filling out the form below for a quote.
