Lincoln Aircare Welder 3/8 Air Line Filter Regulator With Pessure Gauge NSN: 4930-01-510-8460 P/N: 602136
Please fill out the form below for a price quote and availability on this item.
A device consisting of a pneumatic filter and a pressure regulating valve usually assembled as an integral unit. the item is designed to remove foreign matter from the compressed air line and regulate the air flow, thus protecting the air operated equipment for which it is designed.
Technical Characteristics |
|
| For Use With/On: | 4210014889655 |
| Bowl Material: | Zinc alloy |
| Filtration Rating In Microns: | 40.0 nominal |
| Maximum Inlet Pressure Rating: | 250.0 pounds per square inch |
| Maximum Operating Temp: | 150.0 deg fahrenheit |
| Line Connection Thread Size And Series/type Designator: | 0.675-18 nptf |
| Regulator Outlet Pressure Range: | +5.0/+150.0 pounds per square inch |
| Part Name Assigned By Controlling Agency: | Air line filter/regulator |
| Special Features: | Air supply must be dry enough to avoid ice formation at temperatures below +35 degree f. |
This product is only available upon request. Contact us by e-mail or by filling out the form below for a quote.
