Amphenol M83723/77R2025N Electrical Plug Connector NSN:5935-01-044-9596

Regular price $32.50

Electrical Plug Connector

ITAR Registered seal

NSN: 5935-01-044-9596 | Model: M83723/77R2025N

An electrical fitting with electrical contacts, constructed to be affixed to the end of a cable, conduit, coaxial line, cord or wiring for convenience in joining with other electrical connecto (s) or printed wiring board and is not designed to be mounted on a bulkhead, chasses, panel, printed wiring board, or the like. Excludes jack, telephone; jack, tip; plug, telephone; plug tip; insert, electrical connector; connector body (as modified); and socket, plug-in, electronic components. see also lead assembly, electrical; wiring harness (as modified); and cable assembly (as modified) . for items without inserts, see shell, electrical connector.

NSN Properties and Flags
NATO Stock Number
Thread Class
Thread Direction
Body Style
Straight shape, internal coupling
Overall Length
1.420 inches
Overall Diameter
1.510 inches
Environmental Protection
Pressure proof and humidity resistant and shock proof and vibration resistant
Threaded Device Type
Back shell
Mating End Quantity
Contact Position Arrangement Style
19 number 20 single mating end
Contact Removability
Removable single mating end all contact groupings
Polarization Method
Keyway or multiple keyway
Insert Position In Deg
Shell Type
Connector Locking Method
Bayonet latch
Thread Length
0.290 inches
Thread Size
1.188 inches
Terminal Location
Back single mating end all contact groupings
Contact Material
Copper alloy single mating end all contact groupings
Contact Surface Treatment
Gold single mating end all contact groupings
Insert Material
Plastic tetrafluoroethylene single mating end
Contact Surface Treatment Specification
Mil-g-45204 military specification single treatment response single mating end single contact grouping
Terminal Type
Crimp single mating end all contact groupings
Shell Material
Aluminum alloy
Shell Surface Treatment
Shell Material Specification
Qq-a-367 federal specification single material response
Included Contact Quantity
6 single mating end 1st contact grouping
Included Contact Type
Round socket single mating end all contact groupings
Precious Material And Location
Contact surfaces gold
Precious Material And Weight
0.025 gold grains, troy
Precious Material
Test Data Document
81349-mil-c-83723 specification (includes engineering type bulletins, brochures, etc., that reflect specification type data in specification format; excludes commercial catalogs, industry directories, and similar trade publications, reflecting general type data on certain environmental and performance requirements and test conditions that are shown as "typical", "average", "", etc.).
Thread Series Designator
Specification Data
81349-mil-c-83723/77 government specification
