Light Lens NSN:6210-01-152-8032 P/N:r60f24445-split1
Please fill out the form below for a price quote and availability on this item.
Light Lens- A transparent or translucent item designed to enclose or be placed in front of a light source. sections of the lens may be opaque. it may or may not include a holder. it is designed to be either a replacement unit for a specific type of light, such as light, indicator; light, navigational, marine; stop light, vehicular; and lantern, electric or that portion of a switch, (as modified) used as an actuator and having provisions for illumination. see also, window, lighting fixture; globe; electric light; and filter (2), (as modified).
Effective Length: | 0.500 inches nominal |
Effective Width: | 0.750 inches nominal |
Color: | Black inscription |
Color: | White lens |
Hazardous Locations/environmental Protection: | Radio frequency radiation suppressive |
Material: | Plastic filter |
Material: | Plastic lens |
Mounting Device Quantity: | 1 |
Mounting End Diameter: | 0.312 inches nominal |
Mounting Method: | Press fit |
Overall Height: | 1.120 inches nominal |
Overall Length: | 0.760 inches nominal |
Inscription: | Split1 face |
Light Transmission Design: | Translucent lens |
Light Transmission Design: | Translucent filter |
Style Designator: | Flat |
Surface Condition: | Smooth face |
Surface Condition: | Smooth back |
This product is only available upon request. Contact us by e-mail or by filling out the form below for a quote.
